Working height: 45 ft 3.3 in
Platform height: 38 ft 8.6 in
Horizontal reach: 35 ft 1.3 in
Travel height: 45 ft 3.3 in
Platform capacity: 1000 lbs
Platform rotation: 180°
Turntable rotation: 360° (continuously)
Driving speed in transport mode: 0 - 1.43 mph
Driving speed at height: 0 - 0.25 mph
Slope in transport mode: 45% = 25°
Automatic bi-leveling (option): 5° / 15°
Slope at height: 15° / 15°

Machine
Stowed (l x w x h): 17 ft 10.9 in x 7 ft 2.6 in x 7 ft 4.9 in
Total mass without options: 10,494 lbs
Ground clearance: 1 ft 1.8 in

Platform
Standard - Dimensions (LxWxH): 5 ft 10.8 in x 2 ft 7.5 in x 3 ft 7.3 in
Option 1 - Dimensions (LxWxH): 5 ft 1.0 in x 2 ft 7.5 in x 3 ft 7.3 in
Option 2 - Dimensions (LxWxH): 7 ft 10.5 in x 2 ft 7.5 in x 3 ft 7.3 in
Entry width: 2 ft 1.4 in
Entry height: 3 ft 0.2 in
Step in height: 1 ft 3.7 in

12.15 gal fuel tank capacity
Fully proportional controls
Loadsensing hydraulic pump
2 speed track motors
Automatic proportional RPM controller

Complies with ANSI A92 / CSA B354
Tilt alarm
LED flashing lights on rear
Overhead safety crush prevention
Integrated weight system in platform
Dual top railing on basket
Horn

ATD 18.5kW 3 cyl. Kubota Diesel Engine
ATE Fully Lithium Powered (Coming Soon)

4x led work lights on main frame
Led flood light under platform
Non-marking rubber tracks (grey)
Automatic bi-leveling 15° / 15°
HY-Link portal communications

Foldable load carriers on platform (155 lbs)
Extra screw trays
Holder for spray cans
Adjustable work lights on platform
Water level holder in platform
Pail hanger in platform
