Dur-A-Lift DPMS2-47MH


  • Up to 54’ of working height
  • Platform capacity:
  • 400 lbs without jib in operation
  • 400 lbs with jib in use Jib:
  • Top/Rear mounted
  • 1000 lbs maximum capacity
  • Removable jib
  • 80’ of .5” load line with hook and clevis
  • Hydraulic extension
  • Self locking hydraulic operated worm gear winch Bucket mounted hydraulic controls which include:
  • 4 Axis “Single Stick” Control
  • Emergency Power
  • Engine Start/Stop
  • 180 degree bucket rotation
  • Bucket Elevator
  • 24” x 42” x 42” fiberglass climb-in basket with step
  • Vinyl cover with lanyard
  • 22” hydraulic operated bucket elevator
  • Fiberglass Extension boom
  • Front “A” Frame Outriggers
  • Rear “A” Frame, short stance Safety
  • Parking Brake Interlock
  • Outrigger “Down” Interlock Remote lower controls with override.
  • Continuous rotation.
  • Seven GPM open center hydraulic system Non-relube bearings used throughout.
  • Integral hydraulic oil reservoir with dual sight gauges and 17 gallon capacity.
  • Emergency Power Insulated 12V DC hydraulic system.
  • Master / Slave hydraulic leveling with upper and lower control
  • Upper boom storage cradle with latching tie down strap and tubular rubber platform support.
  • Full Body Harness and Lanyard.
  • Standard white urethane paint.
  • Two operator’s manuals and two service manuals.
  • ANSI A92.2 Data plate.
  • 10 Gallon internal hydraulic tank
  • PTO operated hydraulic pump
  • Brand FX Fiberglass Service Body, BFXB-84-LS Body Dimensions:
  • 125” long x 40” high x 94” wide.
  • 84” CA with dual rear wheels.
  • 40” compartment height
  • 18” compartment depth
  • 25” body mounting height Standard Features:
  • Vinyl rock guards
  • Gas fill cup
  • Aluminum understructure
  • White compartment interiors
